Inconel 601
Inconel 601 (UNS N06601) for high-temperature oxidation resistance, bar, sheet, plate, pipe and fittings.
About Inconel 601
Inconel 601 (UNS N06601) for high-temperature oxidation resistance, bar, sheet, plate, pipe and fittings.
Inconel 601 (UNS N06601) is a nickel-chromium alloy with 1.0–1.7% aluminium that forms a tightly adherent oxide skin, giving outstanding resistance to oxidation and cyclic scaling up to 1200 °C. It also resists carburisation and nitriding, which is why it dominates radiant tubes, muffles, thermal-reactor internals and furnace retorts.
Steelco Metal & Alloys stocks Inconel 601 (UNS N06601) in Mumbai, India as a stockist, importer and exporter, and ships to 40+ countries. Every dispatch carries EN 10204 3.1 (3.2 on request) mill test certificates, PMI verification and is open to third-party inspection.
Available forms and size range for Inconel 601
Available Forms
- Sheet
- Plate
- Coil
- Round Bar
- Pipe
- Tube
- Fittings
Size Range
- Sheets 0.5–50 mm
- Bars Ø 6–250 mm
- Pipes 1/2"–24" NB
- Tubes 6–76 mm OD
Chemical composition of Inconel 601 (% by weight)
Values are per the governing ASTM / ASME product specification. A single value means a maximum; a range shows the specified minimum and maximum. Balance is iron.
| Ni | Cr | Al | Fe | Mn | C | Si | S |
|---|---|---|---|---|---|---|---|
| 58.0–63.0 | 21.0–25.0 | 1.00–1.70 | ≤ Balance | ≤ 1.00 | ≤ 0.10 | ≤ 0.50 | ≤ 0.015 |
| range | range | range | max | max | max | max | max |
Mechanical properties of Inconel 601 (annealed, room temperature)
| Property | Typical Value |
|---|---|
| Tensile Strength (min) | 550 MPa (80 ksi) |
| Yield Strength (0.2%) | 205 MPa (30 ksi) |
| Elongation in 50 mm | 30% min |
| Hardness (Rockwell B) | 80–90 approx |
Inconel 601 specifications and international equivalents
| Attribute | Details |
|---|---|
| ASTM / ASME | ASTM B166 / B167 / B168 · UNS N06601 |
| EN / DIN | 2.4851 (NiCr23Fe) |
| JIS | NCF 601 |
| UNS | UNS N06601 |
| Density | 8.11 g/cm³ |
| Size Range | Sheets 0.5–50 mm · Bars Ø 6–250 mm · Pipes 1/2"–24" NB · Tubes 6–76 mm OD |
| Certifications | EN 10204 3.1 / 3.2 MTC · PMI · Third-party inspection |
Use our free metal weight calculator — bars, sheets, plates, pipes and sections.
Typical applications for Inconel 601
Every dispatch is traceable, tested and certified.
Material is supplied with EN 10204 3.1 (3.2 on request) mill test certificates, PMI and spectro verification, and is open to third-party inspection by TUV, SGS, BV, Lloyd’s and IRS from our Mumbai warehouse.
EN 10204 3.1 / 3.2
Mill test certificate with every consignment.
PMI & Spectro
Positive material identification before dispatch.
Third-party Inspection
TUV · SGS · BV · Lloyd's · IRS welcome.
Export Documentation
Full set prepared for 40+ countries.
Other grades you may also need
Ready to price your requirement?
Share your grade, form, size and quantity — our Mumbai desk responds with pricing, stock position and lead time, usually the same working day.
