Inconel 718
Age-hardenable Inconel 718 in bar, sheet, plate, forgings and rings for aerospace, oil & gas and cryogenic service.
About Inconel 718
Age-hardenable Inconel 718 in bar, sheet, plate, forgings and rings for aerospace, oil & gas and cryogenic service.
Inconel 718 (UNS N07718) is a precipitation-hardening nickel-chromium superalloy strengthened by niobium, titanium and aluminium. Solution treated and aged, it reaches 1275 MPa tensile and 1030 MPa yield strength while retaining creep and rupture strength to about 700 °C, making it the standard for gas-turbine discs, downhole tools and high-pressure fasteners.
Steelco Metal & Alloys stocks Inconel 718 (UNS N07718) in Mumbai, India as a stockist, importer and exporter, and ships to 40+ countries. Every dispatch carries EN 10204 3.1 (3.2 on request) mill test certificates, PMI verification and is open to third-party inspection.
Available forms and size range for Inconel 718
Available Forms
- Round Bar
- Forgings
- Sheet
- Plate
- Pipe
- Tube
- Fasteners
Size Range
- Bars Ø 6–350 mm
- Plates 6–80 mm
- Pipes and tubes to drawing
Chemical composition of Inconel 718 (% by weight)
Values are per the governing ASTM / ASME product specification. A single value means a maximum; a range shows the specified minimum and maximum. Balance is iron.
| Ni | Cr | Nb+Ta | Mo | Ti | Al | Fe | C |
|---|---|---|---|---|---|---|---|
| 50.0–55.0 | 17.0–21.0 | 4.75–5.50 | 2.80–3.30 | 0.65–1.15 | 0.20–0.80 | ≤ Balance | ≤ 0.08 |
| range | range | range | range | range | range | max | max |
Mechanical properties of Inconel 718 (annealed, room temperature)
| Property | Typical Value |
|---|---|
| Tensile Strength (min) | 1275 MPa (185 ksi), aged |
| Yield Strength (0.2%) | 1030 MPa (150 ksi), aged |
| Elongation in 50 mm | 12% min |
| Hardness (Rockwell C) | 36–44 aged (NACE max 40) |
Inconel 718 specifications and international equivalents
| Attribute | Details |
|---|---|
| ASTM / ASME | ASTM B637 / AMS 5662 / AMS 5663 · UNS N07718 |
| EN / DIN | 2.4668 (NiCr19Fe19Nb5Mo3) |
| JIS | NCF 718 |
| UNS | UNS N07718 |
| Density | 8.19 g/cm³ |
| Size Range | Bars Ø 6–350 mm · Plates 6–80 mm · Pipes and tubes to drawing |
| Certifications | EN 10204 3.1 / 3.2 MTC · PMI · Third-party inspection |
Use our free metal weight calculator — bars, sheets, plates, pipes and sections.
Typical applications for Inconel 718
Every dispatch is traceable, tested and certified.
Material is supplied with EN 10204 3.1 (3.2 on request) mill test certificates, PMI and spectro verification, and is open to third-party inspection by TUV, SGS, BV, Lloyd’s and IRS from our Mumbai warehouse.
EN 10204 3.1 / 3.2
Mill test certificate with every consignment.
PMI & Spectro
Positive material identification before dispatch.
Third-party Inspection
TUV · SGS · BV · Lloyd's · IRS welcome.
Export Documentation
Full set prepared for 40+ countries.
Other grades you may also need
Ready to price your requirement?
Share your grade, form, size and quantity — our Mumbai desk responds with pricing, stock position and lead time, usually the same working day.
