Monel 405
Free-machining Monel R-405 in bar and rod for valve and pump components in marine and chemical service.
About Monel R-405
Free-machining Monel R-405 in bar and rod for valve and pump components in marine and chemical service.
Monel R-405 (UNS N04405) is the free-machining version of Monel 400, with a controlled sulphur addition of 0.025–0.060% that breaks chips on automatic screw machines. Corrosion behaviour in seawater, hydrofluoric acid and alkaline media matches Monel 400, so it is specified where high-volume machined fasteners, valve stems and instrument parts are required.
Steelco Metal & Alloys stocks Monel R-405 (UNS N04405) in Mumbai, India as a stockist, importer and exporter, and ships to 40+ countries. Every dispatch carries EN 10204 3.1 (3.2 on request) mill test certificates, PMI verification and is open to third-party inspection.
Available forms and size range for Monel R-405
Available Forms
- Round Bar
- Hex Bar
- Wire
- Fasteners
- Machined Components
Size Range
- Round bars Ø 6–200 mm
- Hex bars 6–75 mm A/F
- Wire 1–12 mm
Chemical composition of Monel R-405 (% by weight)
Values are per the governing ASTM / ASME product specification. A single value means a maximum; a range shows the specified minimum and maximum. Balance is iron.
| Ni | Cu | Fe | Mn | S | C | Si |
|---|---|---|---|---|---|---|
| 63.0–Balance | 28.0–34.0 | ≤ 2.50 | ≤ 2.00 | 0.025–0.060 | ≤ 0.30 | ≤ 0.50 |
| range | range | max | max | range | max | max |
Mechanical properties of Monel R-405 (annealed, room temperature)
| Property | Typical Value |
|---|---|
| Tensile Strength (min) | 480 MPa (70 ksi) |
| Yield Strength (0.2%) | 170 MPa (25 ksi) |
| Elongation in 50 mm | 25% min |
| Hardness (Rockwell B) | 75 approx |
Monel R-405 specifications and international equivalents
| Attribute | Details |
|---|---|
| ASTM / ASME | ASTM B164 / B564 · QQ-N-281 · UNS N04405 |
| EN / DIN | 2.4361 |
| JIS | NW 4405 |
| UNS | UNS N04405 |
| Density | 8.80 g/cm³ |
| Size Range | Round bars Ø 6–200 mm · Hex bars 6–75 mm A/F · Wire 1–12 mm |
| Certifications | EN 10204 3.1 / 3.2 MTC · PMI · Third-party inspection |
Use our free metal weight calculator — bars, sheets, plates, pipes and sections.
Typical applications for Monel R-405
Every dispatch is traceable, tested and certified.
Material is supplied with EN 10204 3.1 (3.2 on request) mill test certificates, PMI and spectro verification, and is open to third-party inspection by TUV, SGS, BV, Lloyd’s and IRS from our Mumbai warehouse.
EN 10204 3.1 / 3.2
Mill test certificate with every consignment.
PMI & Spectro
Positive material identification before dispatch.
Third-party Inspection
TUV · SGS · BV · Lloyd's · IRS welcome.
Export Documentation
Full set prepared for 40+ countries.
Other grades you may also need
Ready to price your requirement?
Share your grade, form, size and quantity — our Mumbai desk responds with pricing, stock position and lead time, usually the same working day.
