Copper Beryllium C17300
Free-machining copper beryllium C17300 round bar, hex bar and hollow bar for turned parts. Mumbai stockist and exporter, 3.1 MTC, 40+ countries.
About Copper Beryllium C17300
Free-machining copper beryllium C17300 round bar, hex bar and hollow bar for turned parts. Mumbai stockist and exporter, 3.1 MTC, 40+ countries.
Copper beryllium C17300 has the same 1.80–2.00% beryllium content as C17200 with a controlled lead addition of 0.20–0.60% for free machining. Strength after age hardening is essentially identical to C17200, so it is chosen where high volumes of turned parts — bushings, valve seats, connector pins — must be produced economically.
Steelco Metal & Alloys stocks Copper Beryllium C17300 (UNS C17300) in Mumbai, India as a stockist, importer and exporter, and ships to 40+ countries. Every dispatch carries EN 10204 3.1 (3.2 on request) mill test certificates, PMI verification and is open to third-party inspection.
Available forms and size range for Copper Beryllium C17300
Available Forms
- Round Bar
- Hex Bar
- Hollow Bar
- Wire
- Machined Components
Size Range
- Round bar Ø 3 – 150 mm
- hex bar on request
- solution annealed (A) or age hardened (AT)
Chemical composition of Copper Beryllium C17300 (% by weight)
Values are per the governing ASTM / ASME product specification. A single value means a maximum; a range shows the specified minimum and maximum. Balance is iron.
| Cu | Be | Pb | Ni + Co | Ni + Co + Fe | Al |
|---|---|---|---|---|---|
| ≤ Balance | 1.80–2.00 | 0.20–0.60 | 0.20–— | ≤ 0.6 | ≤ 0.20 |
| max | range | range | range | max | max |
Mechanical properties of Copper Beryllium C17300 (annealed, room temperature)
| Property | Typical Value |
|---|---|
| Tensile Strength (age hardened) | 1140 – 1380 MPa |
| Yield Strength (0.2%) | 965 – 1205 MPa |
| Elongation | 3 – 8% |
| Hardness | 36 – 42 HRC |
Copper Beryllium C17300 specifications and international equivalents
| Attribute | Details |
|---|---|
| ASTM / ASME | ASTM B196 · UNS C17300 |
| EN / DIN | CuBe2Pb (nearest) |
| JIS | JIS C1720 (nearest) |
| UNS | UNS C17300 |
| Density | 8.25 g/cm³ |
| Size Range | Round bar Ø 3 – 150 mm · hex bar on request · solution annealed (A) or age hardened (AT) |
| Certifications | EN 10204 3.1 / 3.2 MTC · PMI · Third-party inspection |
Use our free metal weight calculator — bars, sheets, plates, pipes and sections.
Typical applications for Copper Beryllium C17300
Every dispatch is traceable, tested and certified.
Material is supplied with EN 10204 3.1 (3.2 on request) mill test certificates, PMI and spectro verification, and is open to third-party inspection by TUV, SGS, BV, Lloyd’s and IRS from our Mumbai warehouse.
EN 10204 3.1 / 3.2
Mill test certificate with every consignment.
PMI & Spectro
Positive material identification before dispatch.
Third-party Inspection
TUV · SGS · BV · Lloyd's · IRS welcome.
Export Documentation
Full set prepared for 40+ countries.
Other grades you may also need
Ready to price your requirement?
Share your grade, form, size and quantity — our Mumbai desk responds with pricing, stock position and lead time, usually the same working day.
