Hastelloy B3
Hastelloy B3 (N10675), improved thermal stability over B2, for severe hydrochloric and sulphuric service.
About Hastelloy B3
Hastelloy B3 (N10675), improved thermal stability over B2, for severe hydrochloric and sulphuric service.
Hastelloy B3 (UNS N10675) keeps the hydrochloric-acid resistance of B2 while adding far greater thermal stability, resisting the intermetallic precipitation that embrittles B2 during welding and hot forming. It suits reducing acid service where fabrication, stress relief or intermittent high-temperature exposure is unavoidable.
Steelco Metal & Alloys stocks Hastelloy B3 (UNS N10675) in Mumbai, India as a stockist, importer and exporter, and ships to 40+ countries. Every dispatch carries EN 10204 3.1 (3.2 on request) mill test certificates, PMI verification and is open to third-party inspection.
Available forms and size range for Hastelloy B3
Available Forms
- Sheet
- Plate
- Round Bar
- Pipe
- Tube
- Flanges
- Fittings
Size Range
- Sheets 0.5–50 mm
- Bars Ø 6–250 mm
- Pipes 1/2"–24" NB
- Tubes 6–76 mm OD
Chemical composition of Hastelloy B3 (% by weight)
Values are per the governing ASTM / ASME product specification. A single value means a maximum; a range shows the specified minimum and maximum. Balance is iron.
| Ni | Mo | Fe | Cr | Co | Mn | C | Si |
|---|---|---|---|---|---|---|---|
| 65.0–Balance | 27.0–32.0 | 1.00–3.00 | 1.00–3.00 | ≤ 3.00 | ≤ 3.00 | ≤ 0.01 | ≤ 0.10 |
| range | range | range | range | max | max | max | max |
Mechanical properties of Hastelloy B3 (annealed, room temperature)
| Property | Typical Value |
|---|---|
| Tensile Strength (min) | 760 MPa (110 ksi) |
| Yield Strength (0.2%) | 350 MPa (51 ksi) |
| Elongation in 50 mm | 40% min |
| Hardness (Rockwell B) | 100 max, annealed |
Hastelloy B3 specifications and international equivalents
| Attribute | Details |
|---|---|
| ASTM / ASME | ASTM B333 / B335 / B619 / B622 · UNS N10675 |
| EN / DIN | 2.4600 (NiMo28Fe) |
| JIS | NW 0675 |
| UNS | UNS N10675 |
| Density | 9.22 g/cm³ |
| Size Range | Sheets 0.5–50 mm · Bars Ø 6–250 mm · Pipes 1/2"–24" NB · Tubes 6–76 mm OD |
| Certifications | EN 10204 3.1 / 3.2 MTC · PMI · Third-party inspection |
Use our free metal weight calculator — bars, sheets, plates, pipes and sections.
Typical applications for Hastelloy B3
Every dispatch is traceable, tested and certified.
Material is supplied with EN 10204 3.1 (3.2 on request) mill test certificates, PMI and spectro verification, and is open to third-party inspection by TUV, SGS, BV, Lloyd’s and IRS from our Mumbai warehouse.
EN 10204 3.1 / 3.2
Mill test certificate with every consignment.
PMI & Spectro
Positive material identification before dispatch.
Third-party Inspection
TUV · SGS · BV · Lloyd's · IRS welcome.
Export Documentation
Full set prepared for 40+ countries.
Other grades you may also need
Ready to price your requirement?
Share your grade, form, size and quantity — our Mumbai desk responds with pricing, stock position and lead time, usually the same working day.
