Zirconium 702
Zirconium 702 (R60702) sheet, plate, bar, pipe, tube and fittings for acid plant equipment. Mumbai stockist and exporter, 3.1 MTC, 40+ countries.
About Zirconium 702
Zirconium 702 (R60702) sheet, plate, bar, pipe, tube and fittings for acid plant equipment. Mumbai stockist and exporter, 3.1 MTC, 40+ countries.
Zirconium 702 (UNS R60702) is commercially pure zirconium with excellent resistance to hydrochloric, sulphuric, nitric, phosphoric and organic acids as well as strong alkalis, over a wider concentration range than titanium or stainless steel. It is the standard grade for acetic acid, urea and hydrochloric acid plant equipment.
Steelco Metal & Alloys stocks Zirconium 702 (UNS R60702) in Mumbai, India as a stockist, importer and exporter, and ships to 40+ countries. Every dispatch carries EN 10204 3.1 (3.2 on request) mill test certificates, PMI verification and is open to third-party inspection.
Available forms and size range for Zirconium 702
Available Forms
- Sheet
- Plate
- Strip
- Round Bar
- Pipe
- Tube
- Fittings
- Flanges
Size Range
- Sheet 0.5 – 6 mm
- plate 6 – 60 mm
- bar Ø 6 – 200 mm
- tube Ø 6 – 100 mm
Chemical composition of Zirconium 702 (% by weight)
Values are per the governing ASTM / ASME product specification. A single value means a maximum; a range shows the specified minimum and maximum. Balance is iron.
| Zr + Hf | Hf | Fe + Cr | C | N | O | H |
|---|---|---|---|---|---|---|
| ≤ 99.2 min | ≤ 4.5 | ≤ 0.20 | ≤ 0.05 | ≤ 0.025 | ≤ 0.16 | ≤ 0.005 |
| max | max | max | max | max | max | max |
Mechanical properties of Zirconium 702 (annealed, room temperature)
| Property | Typical Value |
|---|---|
| Tensile Strength (min) | 379 MPa (55 ksi) |
| Yield Strength (0.2%) | 207 MPa min |
| Elongation | 16% min |
| Density | 6.51 g/cm³ |
Zirconium 702 specifications and international equivalents
| Attribute | Details |
|---|---|
| ASTM / ASME | ASTM B551 / B550 / B523 / B493 · UNS R60702 |
| EN / DIN | EN Zr702 (nearest) |
| JIS | JIS H4751 (nearest) |
| UNS | UNS R60702 |
| Density | 6.51 g/cm³ |
| Size Range | Sheet 0.5 – 6 mm · plate 6 – 60 mm · bar Ø 6 – 200 mm · tube Ø 6 – 100 mm |
| Certifications | EN 10204 3.1 / 3.2 MTC · PMI · Third-party inspection |
Use our free metal weight calculator — bars, sheets, plates, pipes and sections.
Typical applications for Zirconium 702
Every dispatch is traceable, tested and certified.
Material is supplied with EN 10204 3.1 (3.2 on request) mill test certificates, PMI and spectro verification, and is open to third-party inspection by TUV, SGS, BV, Lloyd’s and IRS from our Mumbai warehouse.
EN 10204 3.1 / 3.2
Mill test certificate with every consignment.
PMI & Spectro
Positive material identification before dispatch.
Third-party Inspection
TUV · SGS · BV · Lloyd's · IRS welcome.
Export Documentation
Full set prepared for 40+ countries.
Other grades you may also need
Ready to price your requirement?
Share your grade, form, size and quantity — our Mumbai desk responds with pricing, stock position and lead time, usually the same working day.
