ERNiCrMo-4
ERNiCrMo-4 Hastelloy C276 matching TIG rod, MIG wire and electrodes with 3.1 certificates. Mumbai stockist, importer and exporter shipping to 40+ countries.
About ERNiCrMo-4
ERNiCrMo-4 Hastelloy C276 matching TIG rod, MIG wire and electrodes with 3.1 certificates. Mumbai stockist, importer and exporter shipping to 40+ countries.
ERNiCrMo-4 is the matching filler for Hastelloy C276, with about 16% chromium, 16% molybdenum and 4% tungsten. It gives the weld the same resistance as the base metal to hot acids, chlorides and wet chlorine. It is used in chemical plants and pollution-control equipment, and for overlaying steel.
Steelco Metal & Alloys stocks ERNiCrMo-4 (AWS A5.14 · UNS N10276) in Mumbai, India as a stockist, importer and exporter, and ships to 40+ countries. Every dispatch carries EN 10204 3.1 (3.2 on request) mill test certificates, PMI verification and is open to third-party inspection.
Available forms and size range for ERNiCrMo-4
Available Forms
- TIG Filler Rod
- MIG Wire
- Covered Electrodes
- Strip & Overlay
Size Range
- Wire Ø 0.8–1.6 mm
- TIG rod Ø 1.6–3.2 mm
- electrodes Ø 2.5–4.0 mm
Chemical composition of ERNiCrMo-4 (% by weight)
Values are per the governing ASTM / ASME product specification. A single value means a maximum; a range shows the specified minimum and maximum. Balance is iron.
| Ni | Cr | Mo | W | Fe | C |
|---|---|---|---|---|---|
| ≤ Balance | 14.5–16.5 | 15.0–17.0 | 3.0–4.5 | 4.0–7.0 | ≤ 0.02 |
| max | range | range | range | range | max |
Mechanical properties of ERNiCrMo-4 (annealed, room temperature)
| Property | Typical Value |
|---|---|
| Tensile Strength (weld metal) | 690 MPa typical |
| Elongation | 30% typical |
| Corrosion | Matches C276 in oxidising and reducing media |
ERNiCrMo-4 specifications and international equivalents
| Attribute | Details |
|---|---|
| ASTM / ASME | AWS A5.14 ERNiCrMo-4 · A5.11 ENiCrMo-4 |
| EN / DIN | EN ISO 18274 S Ni 6276 |
| JIS | JIS Z3334 YNiCrMo-4 |
| UNS | AWS A5.14 · UNS N10276 |
| Density | 8.89 g/cm³ |
| Size Range | Wire Ø 0.8–1.6 mm · TIG rod Ø 1.6–3.2 mm · electrodes Ø 2.5–4.0 mm |
| Certifications | EN 10204 3.1 / 3.2 MTC · PMI · Third-party inspection |
Use our free metal weight calculator — bars, sheets, plates, pipes and sections.
Typical applications for ERNiCrMo-4
Every dispatch is traceable, tested and certified.
Material is supplied with EN 10204 3.1 (3.2 on request) mill test certificates, PMI and spectro verification, and is open to third-party inspection by TUV, SGS, BV, Lloyd’s and IRS from our Mumbai warehouse.
EN 10204 3.1 / 3.2
Mill test certificate with every consignment.
PMI & Spectro
Positive material identification before dispatch.
Third-party Inspection
TUV · SGS · BV · Lloyd's · IRS welcome.
Export Documentation
Full set prepared for 40+ countries.
